Centrifugal Air Curtains with high quality international standards – CE GS Approved Casing made in Stainless Steel body, which is sealed to resist dust going inside, with fire and corrosion resistance, and easy for cleaning and maintenance.
Stainless Steel Air Curtains give a great appearance & preferred by a lot of food and pharma industries.
| Model: | EAS 3 | EAS 4 | EAS 5 | EAS 6 |
| Body Material: | Stainless Steel (304 Grade) | |||
| Dimension ( mm): | 900 x 230 x 212 | 1200 x 230 x 212 | 1500 x 230 x 212 | 1800 x 230 x 212 |
| Max. Air velocity at Nozzle: | 21 m/s | 21 m/s | 21 m/s | 21 m/s |
| Noise Level dB: | 50 – 70 db | 50 – 70 db | 50 – 70 db | 50 – 70 db |
| No. of Blowers: | 3 | 4 | 5 | 6 |
| No. of Motors: | 2 | 2 | 3 | 3 |
| No. of Shafts: | 1 Single + 1 Double | 2 Double | 1 Single +2 Double | 3 Double |
| Power (W): | 410 W | 560 W | 700 W | 820 W |
| Phase : | Single | Single | Single | Single |
| RPM ( Max/ Min ): | 2700 / 2100 | 2700 / 2100 | 2700 / 2100 | 2700 / 2100 |
| Blower Material: | ABS | ABS | ABS | ABS |
| CFM: | 825 | 1100 | 1380 | 1490 |
| % Insect/ Dust Rejection: | 75% | 75% | 75% | 75% |
| Weight Kgs: | 19 | 22 | 26 | 32 |
| Effective height: | Below 11 feet | |||
| *Parameters may vary 5 – 10% depending on various conditions. | ||||
